Big Tex 12SR
Call (406) 549-4243 For More Information
Pro Series Tandem Axle Single Ram Dump
For professional construction workers, landscapers, and farmers looking for a trailer thats designed for heavy hauls that need smooth dump outs, look no further. Experience a heavy-duty trailer thats purpose-built for your needs, the 12SR Pro Series Tandem Axle Single Ram Dump. Manufactured for strength and durability with steel floors and sides, the 12SR delivers a payload capacity of 8,500 lbs. In other words, its time to get to work.
(406) 549-4243- Overview
- Features/Specifications
- Standard/Optional Equipment
Overview
Big Tex 12SR Pro Series Tandem Axle Single Ram Dump
For professional construction workers, landscapers, and farmers looking for a trailer thats designed for heavy hauls that need smooth dump outs, look no further. Experience a heavy-duty trailer thats purpose-built for your needs, the 12SR Pro Series Tandem Axle Single Ram Dump. Manufactured for strength and durability with steel floors and sides, the 12SR delivers a payload capacity of 8,500 lbs. In other words, its time to get to work.
| SIZE | WEIGHT | DESCRIPTION |
|---|---|---|
| 12' | 3,500# | 83" x 12' Pro Series Tandem Axle Single Ram Dump |
Features/Specifications
Features
| AXLE | (2) 6,000# Quick Lubricating w/Elec. Brakes |
|---|---|
| JACK | 8,000# Top Wind Drop Leg |
| TIRE | ST235/80 R-16 Load Range E |
| FLOOR | 10 Gauge Smooth Steel |
| WHEEL | 16" x 6"; Black Mod, 6 Bolt |
| FINISH | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| LIGHTS | L.E.D. D.O.T. Stop, Tail, Turn and Clearance |
| TONGUE | 6" Channel |
| COUPLER | 2-5/16" Adjustable Forged |
| FENDERS | 9" x 72" 14 Ga. Diamond Plate Double Square Broke |
| ELEC. PLUG | 7-Way RV |
|---|---|
| HITCH TYPE | Bumper Pull |
| MAIN FRAME | 6" x 2" Rectangular Tubing |
| SUSPENSION | Multi-Leaf Slipper Spring w/Equalizer |
| FINISH (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| SAFETY CHAINS | 1/4" Grd. 70 w/Safety Latch Hook (2 each) |
| DUMP BODY SIDES | 24" Tall Sides (12 Gauge) |
| DUMP BODY TOP RAIL | 2" x 2" Square Tubing |
| G.A.W.R. (Ea. Axle) | 6,000# |
| DUMP BODY CROSSMEMBERS | 3" Channel, 16" Centers |
Specifications
.png)
Big Tex 12SR Pro Series Tandem Axle Single Ram Dump
| Model | Description |
|---|---|
| 12SR-12XL | 83" x 12' Pro Series Tandem Axle Single Ram Dump |
Dimensions
| Length | A | B | C |
|---|---|---|---|
| 12' | 144" | 81-3/4" | 62-1/4" |
Trailer Weights & Capacities
| Length | Empty Weight | Payload | Box Capacity |
|---|---|---|---|
| 12' | 3,500# | 8,500# | 6.1 Cubic Yards |
Standard/Optional Equipment
Standard Equipment
- Adjustable 2-5/16" Forged Coupler
- 8,000# Top Wind Drop-Leg Jack
- Lockable Pump and Battery Box Mounted in Front of Bed
- 24" Tall, 12 Gauge Sides w/Formed Channel Supports
- 10 Gauge Steel Floor
- Tarp Mounting Brackets on Front of Bed
- J-Hooks on Sides and Rear for Tarp Control
- Stakepockets Along Sides
- Self Contained Electric/Hydraulic Single Cylinder Lift
- Power Up/Power Down Hydraulic Pump
- 12V Interstate Deep Cycle Battery
- 110V On-Board Battery Charger (5 Amp)
- Premium Brand Axles
- Cambered Axles w/ Quick Lubricating Hubs
- Forward Self Adjusting Electric Brakes on All Hubs
- Grommet Mount Sealed Lighting
- L.E.D. Lighting Package
- Sealed, Modular Wiring Harness
- Complete Break-A-Way System
- Diamond Plate Fenders
- 2" Square Tubing Top Rail on Dump Bed
- Combo Gate (Barn Doors and Spreader Gate)
- (4) 1/2" D-Rings Inside Bed to Secure Equipment
- Spare Tire Mount
- Radial Tires
- Zip Breakaway Cable
Optional Equipment
| Category | Description |
|---|---|
| CARGO CONTROL | Crank Style Roll Tarp |
| RAMPS | 6.5 Slide In Ramp Package |
| TIRE/WHEEL | SPARE TIRE (ST235/80 R-16 LR-E) |
