Big Tex 14DF
Call (406) 549-4243 For More Information
Heavy Duty Drive-Over Fender Equipment/Car Hauler
When you want to widen the scope of what you can haul, you need a trailer with a full-width, 102" deck in front and behind the fenders. Thats what the 14DF Heavy Duty Drive-Over Fender Equipment/Car Hauler offers, and then some. It features a Front Stop Rail, as well as D-Rings and Pockets for securing your gear, plus two 7,000-pound axles and a 36" cleated dovetail. As speaking of those fenders, theyre 3/16" diamond plated drive over fenders, looking good and standing strong, just like you as you go about your equipment hauling tasks.
(406) 549-4243- Overview
- Features/Specifications
- Standard/Optional Equipment
Overview
Big Tex 14DF Heavy Duty Drive-Over Fender Equipment/Car Hauler
When you want to widen the scope of what you can haul, you need a trailer with a full-width, 102" deck in front and behind the fenders. Thats what the 14DF Heavy Duty Drive-Over Fender Equipment/Car Hauler offers, and then some. It features a Front Stop Rail, as well as D-Rings and Pockets for securing your gear, plus two 7,000-pound axles and a 36" cleated dovetail. As speaking of those fenders, theyre 3/16" diamond plated drive over fenders, looking good and standing strong, just like you as you go about your equipment hauling tasks.
| SIZE | WEIGHT | DESCRIPTION |
|---|---|---|
| 20' | 3,340# | 102" x 20' Tandem Axle Equipment Trailer |
| 22' | 3,675# | 102" x 22' Tandem Axle Equipment Trailer |
Features/Specifications
Features
| AXLE | (2) 7,000# Quick Lubricating w/Electric Brakes |
|---|---|
| JACK | 12,000# Drop Leg Jack - Side Wind |
| TIRE | ST235/80 R-16 Load Range E |
| FLOOR | 2" Treated Pine or Douglas Fur* |
| FRAME | 6" Channel |
| WHEEL | 16" x 6" Black Mod 8 Bolt |
| FINISH | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| LiGHTS | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| TONGUE | 6" Channel Fold Back/Wrap |
| COUPLER | Adjustable 2-5/16" Demco EZ Latch |
| FENDERS | 3/16" Diamond Plate Drive-Over |
|---|---|
| G.V.W.R. | 14,000# |
| TOP RAIL | NONE |
| ELEC. PLUG | 7-Way RV |
| HITCH TYPE | Bumper Pull |
| SUSPENSION | Multi-Leaf Spring w/Equalizer |
| CROSSMEMBERS | 3" Channel on 16" Centers |
| FINISH (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| SAFETY CHAINS | 3/8" GRD. 70 w/Safety Latch Hook (2 ea.) |
| G.A.W.R. (Ea. Axle) | 7,000# |
Specifications
Big Tex 14DF Heavy Duty Drive-Over Fender Equipment/Car Hauler
| Model | Description |
|---|---|
| 14DF-20 | 102" x 20' Tandem Axle Equipment Trailer |
| 14DF-22 | 102" x 22' Tandem Axle Equipment Trailer |
Dimensions
| Length | A | B | C |
|---|---|---|---|
| 20' | 240" | 138" | 102" |
| 22' | 263-1/2" | 153" | 110-1/2" |
Trailer Weights & Capacities
| Length | Empty Weight | Payload | Box Capacity |
|---|---|---|---|
| 20' | 3,340# | 10,660# | N/A |
| 22' | 3,675# | 10,325# | N/A |
Standard/Optional Equipment
Standard Equipment
- Rubrail and Tie Down Pockets Along Sides
- (6) D-Rings to Secure Equipment
- 36" Cleated, Self Cleaning Dovetail
- 5 Rear Slide-In Ramps w/ Stabilizer Jacks
- Adjustable 2-5/16" Demco EZ Latch Coupler
- Fold Back/Wrap Tongue
- 12,000# Drop Leg Jack- Side Wind Against Bed
- Fabricated Front Stop Rail
- Quick Lubricating Hubs
- Premium Brand Axles
- Forward Self Adjusting Electric Brakes
- Cambered Axles
- 3/16" Diamond Plate Drive-Over Fenders
- Full Width In Front and Behind Fenders
- Grommet Mount Sealed Lighting
- L.E.D. Lighting Package
- Sealed Modular Wiring Harness
- Spare Tire Mount (Front)
- Complete Break-A-Way System w/Charger
- Zip Breakaway Cable
- Radial Tire
Optional Equipment
| Category | Description |
|---|---|
| BODY | 1/8" Diamond Plate Steel Floor |
| BODY | Blackwood Pro Rubber Infused Floor |
| CARGO CONTROL | 5/8" D-Ring |
| CARGO CONTROL | Recessed D-Ring in Floor (Steel Floor Only) |
| COUPLER | Adjustable Pintle in Channel in Lieu of Coupler |
| COUPLERS | Gooseneck ILO Bumperpull |
| RAMPS | 5 Knee Ramps ILO Slide-In Ramps (19" W) |
| TIRE/WHEEL | Spare Tire (ST235/80 R-16 LR-E) |
| TIRE/WHEEL | Spare Tire Upgrade (ST235/80 R-16 LR-G) |
| TIRE/WHEEL | Tire Upgrade (ST235/80 R-16 LR-G) |
